TEA offers a comprehensive range of thermal test and measurement products for the semiconductor industry. Click any product category below to learn more.

  • Scalability: any chip size (1mm x 1mm, to >50mm x 50mm)
  • Configurability: hot spots (as small as 1mm x 1mm)
  • In-situ TSD (temperature sensing diode), in every 1mm x 1mm area
    – very different from RTD
  • Power density exceeds requirements for HPC and AI chips
  • Conforms to JEDEC standards
  • Can be configured into various power zones (“hot spots”), with temperature sensors at desired locations across the chip
  • Complexity: various packaging formats – WB, FC, COB, BGA, LGA, multi-chip SiP, stacked/3D
  • Flexibility: can integrate with any thermal management solutions, with various die backside metallization options
  • Can enable thermal studies – transient or steady state
  • Can interface with commonly available instrumentation
  • Can be utilized in advanced packaging configurations: 2.5D/3D (TSV, HB), embedded (organic, glass, RDL), …

For special requirements beyond our standard offerings, please contact us.
